| Supply Voltage | 10 – 30 VDC |
| Power Consumption | ≤ 2.5 W |
| Start-Up Time | < 1 s |
| Min Temperature | -20 °C (-4 °F) |
| Max Temperature | +80 °C (+176 °F) |
| Weight | 1305 g (2.88 lb) |
| Protection Class | IP64 / IP65 |
| EMC: Emitted Interference | DIN EN 61000-6-4 |
| EMC: Noise Immunity | DIN EN 61000-6-2 |
| Measuring Length | 3.00 m (9.84') |
| Mean Length per Revolution | 260 mm |
| Wire Material | Coated Polyamide Stainless Steel |
| Wire Diameter | 0.80 mm |
| Housing Material | Steel |
| Draw Wire Housing Material | Aluminum |
| Max. Speed of Wire Displacement | 2.0 m / s |
| Max. Angular Acceleration | 7.0 g |
| Max Extension Force | 9.0 N |
| Min Retraction Force | 5.5 N |
| Actuation Lifetime | 3.0 mio Cycles (Estimated based on ideal conditions) |
| Wire Mounting | M4 Thread |
| Max. Wire Exit Angle | ±3° |
| Technology | Magnetic (≤ 0.09°) |
| Accuracy | ±0.02 % Full Scale Output |
| Repeatability | ±0.003 % Full Scale Output |
| Resolution Singleturn | 16 bit |
| Resolution Multiturn | 12 bit |
| Approx. Linear Resolution | 4 µm (theoretical), limited by mechanics |
| Code | Binary |
| Interface | Profibus DP |
| Profile | DPV0, DPV1 and DPV2 Class 2 (EN50170 + EN50254) |
| Diagnostics | Memory |
| Programming Functions | Resolution, gearing factor (physical resolution) , velocity scaling + filter, preset (zero point), counting direction, limit switches , node number, teach-in, diagnosis |
| Manual Functions | Address selector switch 0-99 and terminal resistor (with connection cap) |
| Transmission Rate | ≤12 Mbaud |
| Interface Cycle Time | ≥ 1 ms |
| Output Driver | Profibus Data Interface, galvanically isolated via opto-couplers |
| Current Consumption | ≤ 230 mA @ 10 V DC, ≤ 100 mA @ 24 V DC |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| MTTF | 109 years @ 40 °C |
| Electrical Lifetime | >10⁵ h |
| Connection Orientation | Radial |
| Connection Orientation (w.r.t Draw Wire) | Radial 9 |
| Connection Type | 2 x M20 Cable Glands |
| Product Life Cycle | Established |
