IXARC INCREMENTAL ENCODERS

Programmable Incremental Encoders

Incremental rotary encoders generate an output signal each time the shaft rotates a certain angle. The number of signals (pulses) per turn, also called PPR, defines the resolution of the device. The internal components of an incremental encoder are much simpler than the ones of an absolute encoder. This fits the need of many applications for simple, cost effective solutions while still providing accurate positioning. They are available with common configurations such as A, B, Z, and inverted signals available as HTL (Push-Pull) or TTL (RS422). POSITAL magnetic encoders can all be configured via the UBIFAST configuration tool: helping reduce inventory levels.

Programmable Pulse per Revolution

Any PPR from 1 to 16,384

High Performance due to Signal Processing

Phase Angle: 90° ± 14°

Industry Leading Sensing Technology

Accuracy ±0.0878°

Programmable Output

Push-Pull (HTL) or RS422 (TTL)

Magnetic Technology

Simple Design – No Code Discs

High Shock and Vibration Resistance

Insensitive to Dust and Humidity

Heavy Duty Enclosures

IP69K and Stainless Steel Versions Available

Large Variety of Flange Configurations

With a Range of Shaft Diameters

Main Variations

Our mission is to help our customers address all problems they can possibly face in the field. That is why we offer a wide range of mechanical and housing variations; ensuring a quality sensor that fits your needs.

Incremental Interface Specifications

See all Configurable Parameters

Compact and Cost Effective Incremental Encoders

Ø36 - 58 mm Housing

Solid or Hollow Shaft

Connector or Cable

Highly Versatile

Find the Incremental Encoder for your application

The Industry Classics

Cube Encoder

Square Flanges

Ø40 & 50 mm Clamping Flanges

Check our Square Flange Design

Through Hollow Shaft

Ø58 – 77 – 100 mm Housing

Shaft from 9.52 mm up to 44.45 mm (3/8” up to 1 ¾”)

Check our Hollow Shaft Encoders

Heavy Duty

IP69K

Stainless Steel Housing

Up to 300g Shock Resistance

Check our Heavy Duty Encoders

Applications

IXARC incremental encoders are ideal for various industries due to their small size and excellent performance. Their economic magnetic design makes them ideal for motor feedback, material handling applications and OEMs.

Medical Equipment Used in MRI and CT Scanner Tables Height Positioning Compact Sizes	Mobile Machines Sensors for Tough Jobs Hazardous Environments High Pressure & Temperature Resistance
Material Handling Efficient, Accurate and Safe Positioning AGV, Conveyors, Baggage Handling, etc.	Renewable Energy Photovoltaic, Turbines, Parabolic Systems Speed Control System Increased Efficiency in Extreme Environments
